2022 Öhlins RXF34 m.2 fork - 29″ / 130mm / 44 offset ***FREE SHIP***

$ 1,180.00

This listing is for one brand new suspension fork


Travel: 130mm

Axle: 110x15mm BOOST

Brake: 74mm post for 160mm

Offset: 44mm

Wheelsize: 29"

Steerer: tapered




aftermarket packaging - including manuals

full manufacturer warranty


Got Questions? Message us!



Manufacturer Specs:



Description

Designed for riders who cover lots of ground — FAST. The new fork replaces the original RXF34, and offers a short-travel 120-130mm setup optimized for lightweight 29er trail bikes. Weighing in at just 1698g, the fork boasts a brand new air spring and damper adapted for the demands of the emerging riding style, while still carrying all the hallmarks of Öhlins’ race-proven performance suspension seen from its long-travel, single-crown cousins — the RXF36 m.2 & RXF38 m.2.

OTX18 — the ‘downcountry damper’

The RXF34 m.2 uses the newly designed OTX18 damper. Sprung out of the highly successful TTX18 found in the Öhlins downhill and trail forks, the OTX18 is purpose-built for lightweight trail bikes. It shares several key components with its bigger TTX18 brother, but weighs 27% less and is optimized for faster and more fluid trail riding, striking the optimal balance between traction, control, weight and stiffness. Like all Öhlins dampers, the OTX18 offers impressive adjustability for fine-tuning, with fifteen clicks of low-speed compression and rebound adjustment alongside three for tweaks to high-speed compression. As always, a large and extensively-tested setting bank is also available for those who wish to customize their ride feel even further.

Lightweight air spring

The new damper is paired with a robust yet lightweight air spring that features a positive and self-adjusting negative chamber. The positive chamber allows riders to tune the spring curve according to their needs using Öhlins’ easy-to-use volume spacer system. The negative chamber, meanwhile, has been designed for fast trail riding and provides a plush initial feel and superb small bump sensitivity. The spring’s surface and seals also minimize friction and breakaway force to enhance the fork’s smooth ride feel.

Race-proven chassis design

With a flex pattern tailored for lightweight trail riding, the RXF34 m.2’s super-stiff chassis delivers point-and-shoot precision steering. This has been achieved via a closed-end outer tube design to increase stiffness, impact resistance and the volume of the lower legs. Increased air volume at the bottom of the fork increases the impact of the air spring on overall performance. This in turn gives the rider more power to fine-tune performance to their liking for greater confidence and control. The RXF34 m.2 also benefits from the same race-proven floating axle design found in the RXF36 m.2 and RXF38 m.2, which decreases friction and further increases stiffness.

Technologies

No one knows suspension like Öhlins, our proprietary technologies — developed from multi-discipline know-how help you ride smoother, faster and push the boundaries of your MTB.

Servicing & Support

Regular and effective maintenance is the key to maintaining the optimum function and performance of your Öhlins suspension forks and shocks. Öhlins products can be serviced at any authorized service center and basic service can be performed by riders with intermediate mechanical skills, using commonly owned tools.

Öhlins riders can safely maintain and service their own forks and rear shocks using our simple step-by-step video guides and PDF manuals, supported by easily available spare parts kits that come complete with everything they need to keep their suspension in peak condition.

Features

OTX18 trail-optimized damper

34 mm stanchions

29” wheels

44 mm offset

130 mm travel

Floating axle design to minimize friction

eMTB approved

Post mount 160 mm rotor size, max 203 mm

Maximum tire size 29 x 2.6”

Weight 1698 g without volume spacers

Axel to crown 541 mm @ 130 mm stroke
